Machinery Details
|
||||
| Horizontal Boring Machine 3 Axis DRO Make: Skoda / Spindle Dia 200 mm Model: W 200 HC X - 10500 mm / Y- 3000 mm / Z - 2000 mm With 3 Axis DRO Bed: 12800 x 3760 mm Attachment: Rotary Table 2000x2000 mm 25 Ton Capacity Facing Chuck: 2000 mm Capacity /Universal Milling Head 360 Deg |  |
|||
| Vertical Turning Lathe 2 Axis DRO / Onen head CNC Control for Siemens 802 Control on one head Make: Titan / Model: SC 53 Chuck Dia 4000 mm / Swing Dia 5300 mm / Max. Ht 2300 mm Capacity: 35 Ton /Vertical Head: 2 Nos Max Horizontal Stroke: 2800 mm / Max Vertical Stroke of Ram: 1500 mm / Tilt + 35Deg Boring Head Spindle Dia 150 mm Spindle Stroke (Z) 1000 mm Vertical Stroke (Y) 1250 mm |
|
|||
| Vertical Turning Lathe Normal Make: Titan / Model: SC 43 Chuck Dia 4000 mm / Swing Dia 4250 mm / Max. Ht 2060 mm Capacity: 30 Ton / Vertical Head: 2 Nos Max Horizontal Stroke: 2400 mm / Max Vertical Stroke of Ram: 1200 mm / Tilt + 35 Deg Side Head Horizontal Stroke 2000 mm Vertical Stroke 1000 mm |
| |||
| Table Type Horizontal Borer 3 Axis DRO Make: Stanko Import Spindle: 160 mm / X &Y : 1400 mm , Z -1600 mm Quil Movement 1000 mm Rotary Table Size: 1800 x 1600 mm Capacity 8 Ton Facing Chuck: 630 mm |
|
|||
| Radial Drilling Machine Make: Batliboi / Model: BR 624 / Drilling Capacity 75 mm MT 5 Make: Stanko Import / Drilling Capacity 100 mm MT 6 Luga Drilling and Tapping Machine: Model: DG 40 W RD machine with digital readout Model: RD 50 W Drilling Capacity 50 mm Distance 1600 mm |  | |||
| Centre Lathe Make: Hindustan Chuck Dia 1200 mm / Lg 30 Ft 4 Feet 6 Feet Bench Grinding Machine Universal Pedestal Grinding Machine Effico EOT Crane Capacity 25 Ton – Qty 2 Nos |  | |||
|
||||
| CNC Profile Cutting Machine LRT - 2.5 Mtr x 12 Mtr x 150 mm MACHINE MODEL L3012/F01/POWER –T CONTROL SYSTEM TEX COMPUTER (POWER-T) MACHINE CUTTING AREA 3000 mm X 12000 mm WEIGHT OF THE MACHINE 3500 kg (APROX) EFFECTIVING CUTTING LENGTH 12000 mm EFFECTIVING CUTTING WIDTH 3000 mm TACK LENGTH 14500 mm TRACK WIDTH 4500 mm MOTORIZED TORCH MOVEMENT 130 mm POSITIONED SPEED (XY) 0-6000 mm/min NUMBER OF FLAME CUTTING TORCHES ONE EOT Crane Electromech Capacity 10 Ton – Qty 2 Nos Can try Crane Electromech 20 Ton Capacity Mobile Crane Escorts Capacity: 12 Ton Welding Machine MMA ARC 400 Qty 5 Nos MMA Essab LHJ 750 Qty 3 Nos CO2 Auto K 600 Qty 6 Nos CO2 Rilon Mig 500 Qty 6 Nos SAW MIZ 1000 Qty 3 Nos MMA SSR 600 Qty 4 Nos |  | |||
|
||||
|
Capacity 25 Ton Qty 2 Nos) Column Boom Welding Machine Qty 2 Nos & 3 Nos Order Placed BOOM LIFT HEIGHT 6000 MM BOOM TRAVERSE LENGTH 6000 MM Vertical Lift Speed: Fixed Speed @ 1000 mm/min* Boom Travel Speed 150 to 1500 mm/min* Trolley Travel Speed Fixed Speed @ 1000 mm/min* Supply : 3 ph AC 415 V / 50 HZ Controls: Remote Pendent / Flux recovery system Welding power source AOTAI Make Single wire package Model: ASAW 1250 Inverter Submerged ARC welding machine |  | |||
|
Heavy Duty Rolling Machine / Plate Pending Machine Himalaya Capacity: 56 mm thk x 3000 mm width Machine Model PNN/30/0 Machine Type Hydraulic Top Roll DIA (Apx) 560 MM Bottom Roll DIA 510 MM Max. Width of Plate 3000 MM Capacity Table in Full Span Plate Thickness for 26 Kg/mm Sq. Yield Point Rolling – Minimum Shell ID 2.5 X Bottom Roll DIA 47 MM (DIA. = 1275 MM) Rolling – Minimum Shell ID 5 X Bottom Roll DIA 56 MM (DIA. = 2550 MM) Prepinching – Minimum Width of Flat 2XT 35 MM (MWF = 70 MM) Prepinching – Minimum Width of Flat 3XT 44 MM (MWF = 132 MM) Year of Manufacture 2013 |  | |||
|
||||
|
Heavy Duty Floor type Lath for Shell Machining CNC Control for Siemens 802 Control / 6000 mm x 20000 mm x 180 Tons MAKE PRECITECH-BANGLORE MODEL 506/11-12 TAIL STOCK TRAVERSE 2000MM TAIL STOCK FEED TRAVERS 500 MM MAX SWING OVER BED 6000 MM MAX JOB WEIGHT POSSIBLE 180 MT MAX CNC TOOL POST:- X - AXIS 800 MM & Z-AXIS 2000 MM |  | |||
|
EOT Crane Electromech Capacity 10 Ton Qty 1 Nos Welding Machine MMA ARC 400 Qty 2 Nos CO2 Auto K 600 Qty 3 Nos SAW MIZ 1000 Qty 2 Nos MMA SSR 600 Qty 2 Nos SHELL ROTATOR Drive unit with VFD Control & Idler Unit Min dia 500 to Max 6000 mm Capacity: 40 Tons & 60 Tons Area of the Machine shop and Fabrication Unit Covered Area: 7000 Sq.Mtr / Open Area : 1.5 Acrs Power Capacity Present: 500 KVA / Proposal: 1000 KVA ( Under Process) DG SET 125 KVA Qty 2 Nos |  | |||
